Flexible copper connections are made of many single tapes which thickness differs from 0,1 to 0,5 mm rivetedor press-welded. Moreover on customer request and depending on further implementation terminals can be silvered, tinned or nickeled.
APPLICATIONS
Frequently used for electrical connections in extreme conditions and environments, laminated connectors are mainly used in the following circumstances:
- Low mechanical vibrations
- Minor thermal contraction and/or expansion of attached units
- Low movements
- Space constraints
If vibration is a critical factor, we suggest using flexible braided connectors.
SPECIFICATIONS
- Tin-plated
- Silver-plated
- Nickel-plated
- Bare copper
- Aluminium alloy
PLATING OPTIONS FOR CONTACT PADS
- Electrolytic tin plating
- Electrolytic silver plating
- Electroless nickel plating
- Lead-free hot-dip tin plating
OPTIONS
- Insulation: Heat shrink PVC and polyolefin,
ceramic heat shield and several other types
of insulation materials are available.
A type
B Type
Type C
| Product Model | Sectional Area(mm²) | Width (mm) | Thickness (mm) | L(mm) | d(mm) |
|---|---|---|---|---|---|
| YLTBR(X)-L×40×5 | 200 | 40 | 5 | Customized | Customized |
| YLTBR(X)-L×40×8 | 320 | 40 | 8 | ||
| YLTBR(X)-L×40×10 | 400 | 40 | 10 | ||
| YLTBR(X)-L×40×12 | 480 | 40 | 12 | ||
| YLTBR(X)-L×40×15 | 600 | 40 | 15 | ||
| YLTBR(X)-L×40×20 | 800 | 40 | 20 | ||
| YLTBR(X)-L×50×5 | 250 | 50 | 5 | ||
| YLTBR(X)-L×50×8 | 400 | 50 | 8 | ||
| YLTBR(X)-L×50×10 | 500 | 50 | 10 | ||
| YLTBR(X)-L×50×12 | 600 | 50 | 12 | ||
| YLTBR(X)-L×50×15 | 750 | 50 | 15 | ||
| YLTBR(X)-L×50×20 | 1000 | 50 | 20 | ||
| YLTBR(X)-L×60×5 | 300 | 60 | 5 | ||
| YLTBR(X)-L×60×8 | 480 | 60 | 8 | ||
| YLTBR(X)-L×60×10 | 600 | 60 | 10 | ||
| YLTBR(X)-L×60×12 | 720 | 60 | 12 | ||
| YLTBR(X)-L×60×15 | 900 | 60 | 15 | ||
| YLTBR(X)-L×60×20 | 1200 | 60 | 20 | ||
| YLTBR(X)-L×80×5 | 400 | 80 | 5 | ||
| YLTBR(X)-L×80×8 | 640 | 80 | 8 | ||
| YLTBR(X)-L×80×10 | 800 | 80 | 10 | ||
| YLTBR(X)-L×80×12 | 960 | 80 | 12 | ||
| YLTBR(X)-L×80×15 | 1200 | 80 | 15 | ||
| YLTBR(X)-L×80×20 | 1600 | 80 | 20 | ||
| YLTBR(X)-L×100×5 | 500 | 100 | 5 | ||
| YLTBR(X)-L×100×8 | 800 | 100 | 8 | ||
| YLTBR(X)-L×100×10 | 1000 | 100 | 10 | ||
| YLTBR(X)-L×100×12 | 1200 | 100 | 12 | ||
| YLTBR(X)-L×100×15 | 1500 | 100 | 15 | ||
| YLTBR(X)-L×100×20 | 2000 | 100 | 20 | ||
| YLTBR(X)-L×100×25 | 2500 | 100 | 25 | ||
| YLTBR(X)-L×120×5 | 600 | 120 | 5 | ||
| YLTBR(X)-L×120×8 | 960 | 120 | 8 | ||
| YLTBR(X)-L×120×10 | 1200 | 120 | 10 | ||
| YLTBR(X)-L×120×12 | 1400 | 120 | 12 | ||
| YLTBR(X)-L×120×15 | 1800 | 120 | 15 | ||
| YLTBR(X)-L×120×20 | 1800 | 120 | 20 | ||
| YLTBR(X)-L×120×25 | 3000 | 120 | 25 | ||
| YLTBR(X)-L×160×5 | 800 | 160 | 5 | ||
| YLTBR(X)-L×160×8 | 1280 | 160 | 8 | ||
| YLTBR(X)-L×160×10 | 1600 | 160 | 10 | ||
| YLTBR(X)-L×160×12 | 1920 | 160 | 12 | ||
| YLTBR(X)-L×160×15 | 2400 | 160 | 15 | ||
| YLTBR(X)-L×160×20 | 3200 | 160 | 20 | ||
| YLTBR(X)-L×160×25 | 4000 | 160 | 25 | ||
| YLTBR(X)-L×160×30 | 4800 | 160 | 30 |
